Seamless 1.8mm 3.5mm Slim Bezel 46inch 49 inch 55 " 2×2 Narrow Bezel LCD Video Wall HD Display Panel
- Place of Origin:
-
China (Mainland)
- Brand Name:
-
SYTON
- Model Number:
-
SYT-2×2 video wall
- Type:
-
TFT
- Application:
-
Indoor
- Viewing Angle:
-
178 /178
- Pixel Pitch:
-
0.4845(H)*0.4845 (V)
- Contrast Ratio:
-
3000:1
- Brightness:
-
450cd/m2
- Response Time:
-
5ms
- Input Voltage:
-
AC100~240V 50 /60 HZ
- Warranty:
-
1 Year, One Year
- After-sales Service Provided:
-
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
- Product name:
-
2×2 lcd video wall
- Certificate:
-
CE/CCC/FCC/ROHS/SAA
- Size:
-
49 Inch
- Optional Function:
-
Customized Logo
- Bezel:
-
3.5mm
- Panel brand:
-
Famous Brand
- Keyword:
-
2×2 video wall
- Trade Terms:
-
FOB, CIF, EXW, etc.
- Material:
-
Metal Case + Toughened Glass Panel
Packaging & Delivery
- Selling Units:
- Multiple of
- Package size per batch:
- 120X40X60 cm
- Gross weight per batch:
- 260.0 kg
- Package Type:
- 2*2 lcd video wall:Packed in Carton case, and Wooden case in total.
- Picture Example:
-
- Lead Time :
-
Quantity(Piece) 1 – 40 >40 Est. Time(days) 3 To be negotiated
Seamless 1.8mm 3.5mm Slim Bezel 46inch 49 inch 55 " 2×2 Narrow Bezel LCD Video Wall HD Display Panel
3.5mm Slim Bezel 49 inch 2×2 Narrow Bezel LCD Video Wall With Samsung/LG HD Display Panel
Description of LCD Video Wall
♦ Excellent super narrow bezel design with just 3.5 mm bezel width between screens
♦ Built-in 3D noise reduction, making the image clean and outline more vivid
♦ FHD display 1920×1080
♦ LED backlit technology brings you perfect visual effect
♦ 4K input supported (Option)
♦ Built-in speakers and remote control supported
♦ Available sizes: 42",46”, 47”, 49, 55”, 60”
Advantages of LCD Video Wall
♦ Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
♦ High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
♦ Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
♦ Low power consumption and low heat radiation
♦ Long service life lowers the cost of usage and maintenance
♦ Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
♦ Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
♦ Economical and practical: High performance and high quality make it cost less.
| Bazel |
3.5mm |
| Resolution | 1920*1080/60Hz |
| screen lift-span | 60,000 hours |
| Aspect Ratio | 16:9 |
| Display Colors | 16.7 Mil (8bit) |
| Brightness | 500cd/m² |
| Contrast Ratio | 4500:1 |
| Response Time | 6ms |
| Viewing Angle | 178°(H)/178°(V) |
| Lifetime | 60,000 hours |
| Input Interface Support | D-15 RGB VGA Input (1) & DVI Input (1) & HDMI Input (1) |
| Power Consumption | ≤180W |
| Working temperature | -20–60℃ |
| Video Support format | Composite video 2(BNC*2) Input & Output (AVI) |
| Signal Control format | RS232 (RJ45-8 interface) Input & Output |
| Case/Trestle | Customized |
| Installing accessories | Customized |
| Language support | Enghlish, Chinese,Spanish, Russian etc. |
| color system | PAL/NTSC/SECAM |
| Operating system | Android OS 4.4 or windows 7 |
| Installation | With wall bracket for each single unit lcd |
| Body size(mm) | 1022.8*557*101.53mm |
| Frame Color | Black |
| Body material | Metal steel plate ,aluminum side(silver, black, golden etc.) |
| Package | Carton, bubble, wooden boxes, Fengwo Carton |
| Sets | Base,screws,pull the explosion screws,keys,power cord, |
main function
Product description
Shenzhen SYTON Technology Co., Ltd. is one of the leading manufacturers of display for commercial use in China,established in 2005.We provide OEM and ODM sales team,’ technical support team,quality control team and R&D team to keep developing new products and meet customers’ special requests,such as appearance design,high brightness requirement,AR anti-glare etc.Every Digital Signage from SYTON has passed strict quality inspection,such as CE,FCC,ROHS,CCC,ISO9001,ISO14001/IP65 Certification.
We are looking forward to establish long-term business relationship with your respected company.
1.Payment term : T.T 30% payment before production,the 70% balance should be paid shipment after inspection.
2.Warranty: 12 months warranty .lifetime maintainance.
3.Remark: ROHS, CE & FCC,SAA ,IP65 certificates in e-file format are available.
4.MOQ: 1pc, sample order are welcome for your evaluation.
